SMK Series Satcom Passivated 2.92mm RF Connector

Gambar besar : SMK Series Satcom Passivated 2.92mm RF Connector Harga terbaik

Detail produk:

Tempat asal:	Cina
Nama merek:	ELT
Sertifikasi:	CE,ROHS
Nomor model:	K-KFD97G

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	10 buah
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Karton Ekspor Standar
Waktu pengiriman:	Dalam 3 minggu
Syarat-syarat pembayaran:	L/C, T/T, Western Union
Menyediakan kemampuan:	35000PCS/tahun

Kontak

Detil Deskripsi produk

jenis:	2.92mm, tipe K, SMK	Kata kunci:	Konektor Panel Flange 2 Lubang
Barang:	Konektor Gelombang Milimeter	pelapisan:	Berlapis emas
Aplikasi:	RF/Satkom	Isolator:	PTFE
Hambatan:	50Ohm	Jenis kelamin:	Perempuan
Menyoroti:	SMK Series 2.92mm RF connector , Passivated 2.92mm RF connector , Satcom 2.92mm RF connector

RF Coaxial Connector SMK Series Female Straight 2 hole flange 2.92mm

K type is also called 2.92 type connector, this series of products is a commonly used millimeter wave connectors, with a frequency of up to 40 GHz, can be used with SMA series and 3.5 series products are interchangeable and adopt air interface.With small size, light weight, high frequency of use, reliable connection, etc.

Features:

It can mate and interchange with SMA series, K series ,2.4mm,3.5mm connectors.
Superior electrical performance up to 40 GHz
It has the advantages of small volume, light weight, high use frequency, reliable connect.
Great for applications that require high frequency transmission
Female contacts have unique three-slot construction
An air dielectric with a loss-loss plastic center conductor support.
It has the high use frequency, reliable connect.

SMK Series Satcom Passivated 2.92mm RF Connector 0

Model Number	L	L1	Description
K-KFD23	10.5 max	0.7	2.92mm K female 2 holes flange rf connector
K-KFD24	10.2 max	0.4	2.92mm K female 2 holes flange rf connector

Specification:

Impedance	50 Ω
Frequency Range	DC - 40 GHz
Voltage Rating	250 VRMS (Max. Sea Level)
Dielectric Withstanding Voltage	750 VRMS (Max. Sea Level)
Voltage Standing Wave Ratio VSWR	≤ 1.05 + 0.005f
Contact Resistance	Center Conductor ≤ 3.0 mΩ
	Outer Conductor ≤ 2.0 mΩ
Insulation Resistance	≥ 5000 MΩ

Inner Conductor	Male plug: Brass, Gold Plated
	Female Jack: BeCu, Gold Plated
Resilient Contact	BeCu, Nickel Plated
Body / Shell / Housing	Brass, Gold Plated Stainless Steel, Passivated
Insulator	PEI
Gasket	Silicone Rubber
Temperature	-55℃ ~ +125℃
Durability	500 Cycles
Torque	0.79 ~ 1.13 N.m

Other 2.92mm Male Female RF Connector

Part Number	Description
K-KFD21	2.92mm Type K Female RF Coaxial Connector
K-KFD87G	Stainless steel 2.92mm Type K Female RF Coaxial Connector
K-KFD42	2.92mm Type K Female RF Coaxial Connector
K-JFD61G	Stainless steel 2.92mm Type K Male RF Coaxial Connector

SMK Series Satcom Passivated 2.92mm RF Connector 1

SMK Series Satcom Passivated 2.92mm RF Connector 2

SMK Series Satcom Passivated 2.92mm RF Connector 3

SMK Series Satcom Passivated 2.92mm RF Connector 4

Application:

Network	Satcom
Computer/LANs	Computer/LANs
Mobile communication	Instrumentation
Base Station	Mobile communication
Outdoor facilities	Radar,microwave
Telecommunications	Instrumentation
Automotive	Jump line join
Basic facility	Radio, TV aerial system
