50Ω 18GHz Male 2 Hole Flange Mount SMA RF Connector for RF Test Fixture or Chassis

Gambar besar : 50Ω 18GHz Male 2 Hole Flange Mount SMA RF Connector for RF Test Fixture or Chassis Harga terbaik

Detail produk:

Tempat asal:	Xi'an, Cina
Nama merek:	ELT
Sertifikasi:	RoHS
Nomor model:	SMA-KFD376

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	MOQ 50 untuk produksi baru
Harga:	Depending on the quantity
Kemasan rincian:	1 pcs/kantong plastik; 100 pcs/karton
Waktu pengiriman:	5-10 hari kerja untuk kuantitas yang ditebar
Syarat-syarat pembayaran:	T/T atau LC
Menyediakan kemampuan:	Sebagai Persyaratan

Kontak

Detil Deskripsi produk

Nama Produk:	Konektor RF SMA	Model:	SMA-KFD376
Rentang Frekuensi:	0,3MHz-18GHz	Impedansi:	50Ω
DWV:	750V	Resistensi Isolasi:	≥5000MΩ
Konduktor Pusat:	Paduan Tembaga, Berlapis Emas	Konduktor Luar:	Paduan Tembaga, Berlapis Emas
Metode Pemasangan:	Pemasangan flensa 2 lubang	Jenis kelamin:	Pria
Isolator:	PTFE	Aplikasi:	Perlengkapan Uji RF, Sasis, Telekomunikasi

Copper Alloy Female/Jack 2 Hole Flange Mount SMA RF Connector Up To 18GHz

Product Description

The SMA RF connector is an extremely widely used small threaded RF coaxial connector. It can be found in a variety of communication equipment and test instruments.

Core Features:

1) Compact Size, Space-Saving

As an ultra-miniature connector, the SMA RF connector is approximately half the size of a traditional N-type connector (about 1/5 of its volume) and extremely light in weight. This makes it ideal for use in electronic devices with compact spaces and high-density wiring requirements, such as PCBs, micro-modules, and portable instruments.

2) Wide Frequency Range, Excellent Performance

This is one of the biggest advantages of the SMA RF connector. It features an extremely wide operating frequency range, usually up to 0 - 18 GHz, and some high-quality or specially designed models can even extend to 26.5 GHz. It can effectively reduce reflection and loss during high-frequency signal transmission, ensuring signal integrity.

3) High Reliability for the Connection

Different from the bayonet connection of BNC connectors, the SMA RF connector adopts a threaded locking mechanism. This design ensures a very firm connection, with excellent vibration and impact resistance, which can effectively prevent accidental loosening in harsh environments and guarantee long-term connection stability.

Technical Data

Outline Dimension: Copper Alloy Gold Plating Female 2 Hole Flange Mount SMA RF Connector up to 18GHz

Applications

Xi'an Elite Electronics is a leading manufacturer of Systematic Interconnection Solutions, serving industries including:

Aerospace
Aviation
Navigation
Radar systems
Communications
Measurement equipment
Electronics

Our products use premium materials and strict manufacturing processes to ensure durability and reliability in harsh environments.

Packing & Shipping

Packaging: Each Copper Alloy SMA RF Connector is securely packaged in a sturdy cardboard box with foam padding to prevent transit damage.

50Ω 18GHz Male 2 Hole Flange Mount SMA RF Connector for RF Test Fixture or Chassis 2

Shipping: We use reliable courier services for safe and prompt delivery. All shipments include tracking numbers and are packed securely to prevent mishandling during transportation.
